Пътеизмерител EM-SAT 80 Plasser 1996 година

Sales information

• Seller - REMTECHNOLODGY LTD (REMTECHSTROY GROUP)
• Location - EU, Western Europe
• Price EXW -  is available on request
• REM commission - ***
• The price is FOB Port of Bulgaria: For Price and More Information Call.

=======================================================================

• Broad Gauge Track 1435 mm:
• The Optional Broad Gauge Track 1520 mm: The rebuild in REM plant

Product information

Producer

Brand

 The EM-SAT (short for receiver-satellite) is a Track survey car EM-SAT 80 Plasser of laser based on a long chord measurement of track geometry receives (relative track position). The correction data obtained in this way are used to control the stuffing / straighteners during the mechanized track maintenance.

It consists of the main machine with laser receiver unit and a removable, self-propelled satellites with laser transmission unit..

Amenities:
Spacious, air-conditioned cabin with working cab and computer workstation
self-powered satellite for receiving the laser gun
8-channel recorder system
Printers for graphics and data printouts (continuous printing up to A3)
Creating disks for automatic Stopfmaschinenführung by ALC using GVM program

Performance parameters:

After entering and calculating the setpoints, the EM-SAT - depending on the track geometry - work in single mode up to 2,000 m / h, in conjunction with the FPM (fixed point gauge) 1500 m / h The track geometry (curve radii) and weather conditions (fog, solar radiation, etc.) significantly influence the performance. It works with laser chord lengths up to 250 m. It takes up and teardown of the machine about 10 minutes.

Our software for detecting the measured data allows at variable intervals ranging from 0.6 to 5.0 m and acceptance tests at parties perform roadways and documented.


  Drawing





Model

 EM-SAT 80 Plasser

Year model

 1996

Chassisnumber

is available on request

Vehicle information

Registration number

is available on request

Weight (kg)

 31000

Latest inspection (revision)

 10.09.2004 (valid revision to 10.09.2012)

REM inspection ( are granted upon request, contact our regional office or agent)

 15.11.2012

Transmission

Unknown

Engine/Fuel

Engine volume

is available on request

Engine output

is available on request

Fuel type

Diesel

Number of fuel tanks

01

Load details

Load dimensions (l/w/h)

 L = 14750 / W = 3000 / H = 3200 mm

Payload (kg)

N/A

Truck details

Cabin

Unknown

Axle type

Unknown

Hydraulics

N/A

Pull-hook

N/A

Accessories

N/A

Euro class

N/A

Suspension

Front shaft

N/A

Drive shaft

N/A

Bogie

N/A

Tractor

Disc

N/A

Locking

N/A

Other information



 GB: Ballast profiler

  Last inspection 20.10.2008, last service 20.10.2014.

REM inspection 15.11.2012 (are granted upon request, contact our regional office or agent)

  *****

  REM options:
